How to Mount a Dryer on the Wall: A Complete Step-by-Step Guide

If you're tight on floor space in your laundry room, a wall-mounted dryer can be a game-changer. Whether you're outfitting a small apartment or a compact utility room, mounting your dryer on the wall frees up valuable space and gives your setup a clean, modern look.

This guide walks you through everything you need to know — from tools and safety checks to the final installation.

Why Wall-Mount a Dryer?

• Saves floor space — ideal for small laundry rooms or closets
• Ergonomic loading height — no more bending down
• Cleaner look — a streamlined, built-in appearance
• Stackable alternative — useful when you can't stack due to model incompatibility

Before You Begin: Important Checks

Not every dryer can be wall-mounted. Before buying a bracket or picking up a drill, confirm the following:

1. Check Your Dryer's Compatibility

Only manufacturer-approved dryers can be wall-mounted. This is one of the most important things to verify before you start. Heat pump dryers are generally not suitable for wall mounting unless the manufacturer's manual clearly states otherwise. Heat pump technology uses a refrigerant circuit and internal components that are sensitive to orientation and vibration — mounting them on a wall without explicit approval can void your warranty and create a safety hazard.

Always check the dryer's official installation manual or call the manufacturer's support line to confirm wall-mount compatibility for your specific model.

2. Know Your Wall Type

Most Australian laundries have one of three wall types — each requires a different drilling approach, covered in detail in the installation steps below.

Stud Walls (plasterboard/drywall): Framed walls with timber or metal studs behind plasterboard. The bracket must anchor into studs — plasterboard alone cannot bear the weight.

Brick or Masonry Walls: Solid and strong when drilled correctly. Requires a hammer drill, masonry bits, and dynabolts or masonry anchors. No stud finder needed — drill directly into the brick (not the mortar joints).

Tiled Walls (the most common laundry wall in Australia): The trickiest wall type for DIYers. Cracking tiles is a common and costly mistake. This requires a specialised tile drill bit and careful technique — see Step 4 for the full process. If you have expensive or large-format tiles, calling a professional is strongly recommended.

3. Check Electrical and Venting Access

Make sure your chosen wall location gives you access to:

• A suitable power outlet (240V for electric dryers in Australia)
• Venting to the outside (if your dryer is not a ventless/condenser model)

Tools and Materials You'll Need

• Wall-mount bracket kit (model-specific, manufacturer-approved)
• Stud finder (for stud walls)
• Level
• Hammer drill with masonry bits (for brick or tiled walls)
• Diamond-tipped tile drill bit (for tiled walls)
• Screwdriver
• Measuring tape
• Pencil
• Masking tape (to prevent tile slipping)
• Masonry anchors or dynabolts rated for your dryer's weight
• A helper (highly recommended — dryers are heavy!)

Step-by-Step Installation Guide

Step 1: Read the Manufacturer's Instructions

Every dryer and bracket kit is different. Before anything else, read the installation manual that came with your bracket. It will specify the correct mounting height, screw sizes, and load ratings.

Step 2: Find and Mark the Drill Points

• Stud wall: Use a stud finder to locate studs and mark their centres with a pencil.
• Brick wall: Hold the bracket in position, use a level, and mark the hole positions directly.
• Tiled wall: Hold the bracket in position, use a level, and mark with a pencil. Apply masking tape over each mark so the drill bit doesn't wander when starting.

Step 3: Mark the Bracket Position

Hold the mounting bracket against the wall at your desired height. Use a level to ensure it is perfectly horizontal, then mark the screw hole positions.

Tip: The recommended mounting height is typically so that the dryer door sits at a comfortable working height — around chest level. Check your manual for the exact specification.

Step 4: Drill the Pilot Holes

• Stud wall: Use a wood bit slightly smaller than your screw diameter.
• Brick wall: Use a hammer drill with a masonry bit, then insert dynabolts or masonry anchors.
• Tiled wall: Start with a diamond tile bit at slow speed (no hammer), break through the tile, then switch to a masonry bit and hammer mode to continue into the wall behind.

Step 5: Attach the Mounting Bracket

Align the bracket with the holes and drive in the screws or bolts firmly. Do not overtighten on tiled surfaces — you could crack the surrounding tiles. Use a level to double-check the bracket is straight before fully tightening.

Step 6: Prepare the Dryer

Some wall-mount kits require you to attach a hanging rail or adapter plate to the back of the dryer before it can be lifted onto the bracket. Do this step on the floor before lifting.

Step 7: Hang the Dryer

This step requires at least two people. Carefully lift the dryer and hook it onto the wall-mounted bracket. Follow the manufacturer's instructions to lock it into place — most systems use a click-and-lock or bolt-through mechanism.

Step 8: Connect Power and Venting

• Plug the dryer into the power outlet.
• Attach the ventilation duct if your dryer requires external venting. Make sure the duct is not kinked or blocked.

Step 9: Test the Installation

Gently try to rock the dryer to check it is firmly secured. Run a short cycle to confirm everything is working correctly. Listen for any unusual vibrations that might indicate the bracket is loose.

🎬 Watch: How to Wall-Mount a Dryer (Video Guide)

Prefer to follow along visually? This step-by-step video walks you through the full wall-mounting process and is a great companion to this guide:

▶️ How to Hang Your Dryer Like a Pro: Easy Wall Mounting Guide

The video covers locating the right position, securing the bracket, and safely hanging the dryer — ideal if you're a visual learner or tackling this for the first time.

Safety Tips

• Only mount manufacturer-approved dryers. If your manual doesn't mention wall mounting, do not proceed.
• Never mount on a wall that cannot support the weight. If in doubt, consult a professional.
• On tiled walls, never use a hammer drill through the tile itself — only through the substrate behind it.
• Always use the bracket kit recommended by the dryer manufacturer. Universal brackets may not be rated for your specific model's weight.
• Keep ventilation clear. A blocked vent is a fire hazard.
• Do not overload the dryer after wall mounting — exceeding the load capacity puts extra stress on the bracket.
• Check the bracket periodically (every 6–12 months) to ensure all screws remain tight.

Why Hire a Professional? The Hangmaster Can Help (Perth)

Wall-mounting a dryer sounds simple — until you crack a tile, strip an anchor, or realise the bracket isn't level after the dryer is already hung. These mistakes are expensive and, more importantly, a safety risk.

The Hangmaster is Perth's specialist in laundry installations. They drill through tiled walls every day without cracking a single tile, select the right fixings for every wall type, and ensure your dryer is mounted safely and level. Best of all, every installation comes with a lifetime workmanship guarantee — so you're fully covered long after the job is done.

👉 Book a laundry installation with The Hangmaster in Perth

Final Thoughts

Wall-mounting a dryer is a practical, space-saving upgrade — but it pays to go in prepared. Confirm your dryer is manufacturer-approved for wall mounting, understand your wall type (especially if you have tiles), use the right drill bits, and never lift the dryer alone.

If you're in Perth and would rather leave it to the experts, The Hangmaster offers professional laundry installation services that take the guesswork — and the risk — out of the job entirely.

Have questions about your specific dryer model or wall type? Leave a comment below or get in touch with The Hangmaster for a professional assessment.
